T.O. MOBILE

Length (O.A vehicle only) : 4.35 m Width O.A : 3.86 m Height O.A : 1.94 m Weight in air : 3.5 tons Trench depth :2 m Trench width :340 mm Total power : 317 kW (425 HP) Speed on tracks : 700 m/h

Length (O.A.) : 6.40 m Width (O.A. with tracks) :5.30 m Height (O.A.) :3.50 m Weight in air : 21.3 tons Trench depth : up to 3 m Trench width (standard) : 580 mm Total power :1179 kW (1600 HP) Max. rating depth : 500 m Speed on tracks : 2,500 m/h

Length (O.A.) : 6.20 m Width (O.A. with tracks) : 4.30 m Height (O.A.) : 2.90 m Weight in air : 15 tons Trench depth : up to 3 m Trench width (standard) : 480 mm Total power : 880 kW (1200 HP) Max. rating depth : 500 m Speed on tracks : 2,500 m/h

Length (O.A.) : 6.50 m Width (O.A. with tracks) : 3.40 m (4.3m for VSW) Height (O.A.) : 2.80 m Weight in air : 13 tons (9.4 tons for VSW) Trench depth : up to 2.20 m Trench width : up to 480 mm Total power : up to 440 kW (600 HP) Max. rating…

Length (O.A.) : 5.80 m Width (O.A. with tracks) : 3.40 m Height (O.A.) : 2.50 m Weight in air : 10 tons Trench depth : up to 2.00 m Trench width : up to 340 mm Total power : 300 kW (400 HP) Max. rating depth : 2,500 m Speed on tracks : 2,500…

Length (O.A.) : 5.00 m Width (O.A. with tracks) : 3.30 m Height (O.A.) : 2.50 m Weight in air : 8.3 tons Trench depth : up to 1.00 m Trench width : up to 340 mm Total power : 150 kW (200 HP) Max. rating depth : 2,500 m Speed on tracks : 2,500…
